Chicago Pneumatic 1/4 in Hexagon Straight Cushion Pneumatic Screwdriver - CP 6151630090

The CP2816/CP2817 Series are 1/4" hex pistol cushion clutch screwdrivers designed for your heavy duty applications. Well-balanced and lightweight design based on rugged aluminum housing with a comfortable rubber grip to ensure operator comfort.

Features:

• Reliable cushion clutch for various fastening applications
• Keyless quick torque setting
• Robust aluminum body and clutch housing, even for heavy duty applications
• Rubber grip and one-hand reverse button for operator comfort

Specifications:

• Adjustment: Key
• Body: Aluminum
• Free Speed: 1300 rpm
• Length (L): 250mm
• Reversible: Yes
• Sound Power: 94 dB(A)
• Sound Pressure: 83 dB(A)
• Country of Origin: Hungary
• Customs Tariff: 84671190
• Air Consumption at Free Speed: 4 l/s
• Air Inlet Thread Size: 1/4 in
• Air Inlet Thread Type: BSP
• Clutch Type: Cushion Clutch
• Clutch Housing: Steel
• Handle Type: Pistol
• Height (H): 37mm
• Main Material Type: Aluminum, Composite Over-Sleeve
• Maximum Dynamic Air Working Pressure: 6.3 bar
• Maximum Torque in Forward: 6 Nm
• Minimum Hose Diameter (16 ft Hose Length): 0.25 in
• Minimum Torque in Forward: 2 Nm
• Output Drive Size: 1/4 in
• Output Drive Type: Hexagon
• Output Retainer Type: Quick Change
• Starting System: Push Start
• Torque Control System: Non Shut-Off-Clutch
• Vibration: <2.5 m/s sq
• Width (W): 37mm
• Weight: 0.9 kg

Digital Assets:

• CE Certificate
• UKCA Declaration of conformity
• Safety Information and Operator's Manual
• Exploded View
