Stahlwille Transducer Laboratory with Case, Size 1S, 1 - 10 Nm - ST 96524011
A Transducer Laboratory Tool is a specialized piece of equipment used in laboratory settings to test, calibrate, or evaluate transducers. These tools play a critical role in ensuring the proper functionality, accuracy, and performance of transducers that convert physical quantities like pressure, temperature, force, or sound into electrical signals. In a lab, these tools are used for research, development, and quality control purposes, helping to optimize transducer designs, improve sensor accuracy, and test new materials or technologies for sensing applications.
Features:
- Patented
- For laboratory environments
- Optimized measuring range
- For calibrating torque wrenches and torque screwdrivers
- For use together with perfectControl calibrating unit No 7794 or calibration system No 7706
- High degree of accuracy thanks to conversion and digitization of readings within the transducer itself
- High-grade self-locking precision plug
- Not susceptible to lateral forces due to low-profile construction
- DAkkS calibration certificate
- Maximum display deviation value +/- 0.5% of the reading
- Further details on request
- Supplied in sturdy plastic box
- The Quick Release safety lock prevents unintentional loss of insert tools. These click securely into place and are only released again at the push of a button for a quick tool change
- Our torque tools, transducers and test equipment have an official, internationally recognized calibration certificate in accordance with the requirements of DIN EN ISO/IEC 17025:2018 for the traceability by our in-house DAkkS-accredited calibration laboratory
Specifications:
- Display Deviation +/- 0.5%: 1 - 10 Nm
- Display Deviation +/- 0.5%: 0.74 - 7.4 ft.lbs
- Display Deviation +/- 0.5%: 8.9 - 88.5 in.lbs
- Internal Square Size: 1/4 in
- Mount Arm: 1 Nm
- Nominal Value: 10 Nm
- Size: 1S
- Overall Weight: 3.82 lbs
Product Dimension (Refer Image):
